General Product Description:

3M Marine Adhesive/Sealant 5200 is a one-part polyurethane that

chemically reacts with moisture to deliver strong, flexible bonds.

It is strong and flexible whether used as a glue or a sealant.

It has excellent adhesion to wood, gelcoat and fiberglass.  It forms a

watertight, weather-resistant seal on joints and boat hardware, above

and below the waterline.  In addition, its flexibility allows for dissipation

of stress caused by shock, vibration, swelling or shrinking.

Allows for structural movement and is resistant to shock,

vibration, weathering and salt water.  Use on fiberglass, wood and

metal above or below the waterline.

Easy to apply with manual caulking gun.  Remains workable with trowel

or spatula up to four hours after application. Won't sag or flow in vertical

or horizontal seams.

Applications:
Examples of the bonding and sealing jobs this product can handle:

• Fiberglass deck to fiberglass hull

• Wood to fiberglass

• Portholes and deck fittings

• Hull seams above and below water line

• Center board trunk joints

• Between struts and planking

• Stern joints

• Deck housings

Physical Properties:

Base:                                                                      Polyurethane

Density lbs/Gallon:                                              11.3 lbs/gallon

Color:                                                                     White

Solids Content:                                                     97%

Consistency:                                                         Medium paste

Service Temperature:                                           -40°F (-40°C) to 190°F (88°C)

Shore A Hardness:                                              68 (cured condition)

Specific Gravity:                                                   1.36

Coverage:              (10 oz.) 1/8 inch (0.3175 cm) bead = 120 lineal feet (36.6 m)

Click here to download a copy of 3M’s Technical Data Sheet

Click here to download 3M’s 5200 Product Brochure

Application of Adhesive Sealant:

Abrading the surfaces with a 180 grit to 220 grit abrasive, and subsequently

wiping off residue, will enhance the bond strength.  Cut tip of the nozzle to

desired bead size.  If using a 10 fl. oz. cartridge, knock out the bottom seal

with a hammer and place the cartridge in a caulk gun. Apply 3M Marine

Adhesive/Sealant 5200 to the seam or part to be bonded.  Position parts.

Tool material to desired appearance.  Remove excess material with 3M

General Purpose Adhesive Cleaner #08984.

Application Notes:

When using this sealant with metals, it may be necessary to prime the surface

to achieve adequate adhesion and durability of the bond.  Scotch-Weld

Structural Adhesive Primer EC-1945 B/A may be used for priming of most metals.

Precautions:

Avoid eye contact—may cause irritation.  Avoid breathing of vapors—may

Cause irritation of respiratory tract.  Download, read and understand

The necessary precautions contained in the MSDS before using this substance.

Click here to download a copy of the MSDS (Material Safety Data Sheet)

Packaging:

Comes packed in 10 ounce calking tube.
